Description
| Input | |
| Capacity(VA) |
5500VA |
| Voltage(DC) |
48V |
| Nominal Voltage |
220VAC/110VAC |
| Frequency |
50-60Hz Auto Sensing |
| Output | |
| Wattage | 5000W |
| Voltage | 220VAC/110VAC(± 10% UPS Mode) |
| Frequency | 50/60Hz |
| Waveform | Pure Sinewave |
| Transfer Time(AC to DC) | <8ms |
| Transfer Time(DC to AC) | <8ms |
| Output Voltage Regulation | 10%rms |
| Bypass Mode | Yes |
| Saver Mode | Yes |
| Efficiency | >98% |
| Battery/Solar | |
| Charging Current | 40/20A |
| Maximum PV Array Power | 3200W |
| PWM Input Voltage Range | 60V-105VDC |
| Maximum PV Array Open Circuit Voltage | PEM 105VDC |
| Maximum Solar Charging Current | 80A |
| Environment | |
| Temperature | 0-40°C |
| Humidity | C0-95%, Non Condensing |
| Accoustic Noise(db) | >55dB |
Please Note
Inverters need installation by a Qualified Electrician ( And authorized CoC to ensure correct installation and warranty cover )
